iGate AP1OH
Overview:
The iGate AP1OH Series access point deliver high performance and superb user experience for medium density outdoor environments. The iGate AP1OH Series are part of the VNPT Technology ‘s Total Wi-Fi Solution of 802.11ac-enabled access points, delivering a robust mobility experience. In addition, the devices can be used to integrate in other wifi solutions that comply with standards protocols (eg. RADIUS, CAPWAP, EAP, etc.)
Featuring 802.11 ac Wave 1 with 3x3 MIMO and Band Steering, the iGate AP1OH Series enable an all wireless digital work environment.
With a maximum concurrent data rate of 1300 Mbps in the 5GHz band and 900 Mbps in the 2.4 GHz band, the iGate AP1OH Series bring an always-on wireless network experience with the performance required for Enterprise and Communications Service Provider (CSP). It is a deal for medium density indoor environments across verticals.
HIGHTLIGHTS
- High reliability
- Dual Power Supply
- Water Proof
- Lightning Protection
- Easy Management
- WebGUI/CLI
- VNPT Technology’s ONE Controller
- Global Standards
- IEEE 802.11b/g/n@2.4G
- IEEE 802.11a/n/ac@5G
- Flexible Configuration
- Plug and Play
- Remote configuration
- Automatic FW Ugrade
- Multi-WAN
- Ethernet
- Repeater
- Dual Band Radio
- Software-configurable dual band radio (2.4GHz & 5GHz)
- MIMO Antenna
- 3x3 MIMO
- External Antenna
- Wi-Fi Offload
- Non Seamless Wi-Fi
- Offload (NSWO)
- High Performance
- 1.7 Gbps BW
- Security
- Captive Portal 802.1x WPA/WPA2
Key features:
Wireless Features
- Operating Mode: AP, Repeater
- Active Dual Band: 2.4 GHz & 5 GHz
- Band Steering (AP 1101OH model)
- Limited Concurrent Client (CCU)
Multi-WAN Features
- Wireless WAN conectivity (Repeater)
- Ethernet WAN Conectivity
Management Features
- Local Management with WebGUI/ CLI/Telnet
- Remote Management with VNPT Technology ‘s ONE Controller
- Device Information, Connection Statistic, Station monitoring
- Diagnostics Tool: Ping, Trace, Log
- Upgrade FW: Local, Remote
- Backup, Restore Configuration
Security Features
- WPA-PSK, WPA2-PSK, WPA-EAP & WPA2-EAP
- 802.1x Authentication (EAP- SIM/ TLS/TTLS/SIM/AKA/AKA), Captive Portal, Mac based
- WEP, TKIP & AES Encryption
- MAC Filtering
- Hidden SSID
- SPI Firewall
- Access Control by SSID
Network Features
- Forward & Routing Traffic: Bridging/ Routing/ Static routing
- DHCPv4/DHCPv6 (Server, Client)
- PPPoE Client
- VPN Passthrough
- VLAN/IPSEC/PPTP/L2TP
- IPv4/IPv6 Dual Stack, IPv6 only
- NAT & Port Forwarding
- DNS/DDNS
- HTTP Redirect (Captive Portal Authentication)
Protocols
- Management: HTTP, CAPWAP
- Authentication: RADIUS,EAP
Specifications:
| Hardware | |
| CPU | Freescale P1020 Dual Core 800MHz |
| RAM | 256MB DDR3 |
| Flash | 256MB NAND |
| Interfaces | |
| WAN | 1 x 10/100/1000 Base -T (RJ-45), PoE support |
| Ext. Antenna | 3 x N-Type connectors |
| Powers | |
| Types | PoE 802.3at/af, 48V - 1A |
| Power Consumption | 15W (MAX) |
| LEDs & Buttons | |
| Button | 1 x Reset Button |
| LED | 1 x Power/SYS LED 1 x WAN LED 2x WiFi LED |
| Certificate | |
| QCVN 65 | QCVN 65 for 5GHz |
| QCVN 47 | QCVN 47 for 2.4GHz |
| WiFi | |
| IEEE Standards | 802.11 a/b/g/n/ac wave 1 802.11 a/b/g/n/ac wave 1 802.11i security & 802.11v |
| PHY Rate | 2.4GHz: 450 Mbps (AP1101IH/ AP0101IH model) 900Mbps (AP0201IH model) 5GHz: 1300 Mbps (AP1101IH model) |
| Channel Bandwidth | 2.4GHz: 20/40MHz 5GHz: 20/40/80MHz |
| Frequency | 2.4 - 2.4835GHz 5.170 - 5.835GHz |
| Radios | Single Band (AP0101IH/ AP0201IH model) Dual Band (AP1101IH model) |
| Antenna | 2.4GHz: MIMO 3x3 5GHz: MIMO 3x3 External Omni 14dBi (2.4GHz) External Omni 19dBi (5GHz) |
| EIRP | 23dBm (2.4GHz) 25dBm (5GHz) |
| SSID | 8 SSIDs (AP0101IH model) 16 SSIDs (AP0201IH/AP1101IH model) |
| CCU | 35 User/Radio (AP0101IH model) 70 User/Radio (AP0201IH/ AP1101IH model) |
| Others | |
| Operating | 0ᵒC ÷ 50ᵒC Humidity ≤100% |
| Storage | -40°C ÷ 80°C |
| Water Proof | IP67 |
| Lightning Protection | 3KV |
| Mounting | Wall/Pole |
| Dimension | 265 x 265 x 65 mm |
