Overview:

iGate XSW050-NS device is a next-generation optical modem developed by VNPT Technology, applying XGS-PON transmission technology with symmetrical speeds up to 10 Gbps, delivering ultra-fast and stable Internet access. The device is equipped with 5 high-speed Ethernet ports, including one 2.5 Gbps port and four 1 Gbps ports, flexibly meeting wired network connection needs for homes or businesses.

iGate XSW050-NS supports Wi-Fi broadcasting on dual bands of 2.4 GHz and 5 GHz, utilising 2x2 MIMO technology on each band to optimise transmission speed and wireless connection stability. The device also allows integration with VNPT Technology’s Mesh Wi-Fi Access Point system, supporting automatic configuration and synchronisation, expanding Wi-Fi coverage range, and ensuring smooth connectivity throughout the entire usage space.

As part of VNPT Technology’s optical network ecosystem, the iGate XSW050-NS is compatible with popular OLT standards such as Nokia, Huawei, ZTE, and Dasan, while meeting the international ITU-T G.9807.1 standard. The device is suitable for deployment in network models like FTTH, FTTB, and POL, helping to build high-speed, modern, and efficient network infrastructure.

Key features:

• High-speed XGS-PON transmission technology: Supports symmetrical upstream and downstream speeds of up to 10 Gbps, delivering ultra-fast and stable internet connectivity.
• High-performance wired connections: Equipped with 1 XGS-PON port, 1 Ethernet LAN port (2.5 Gbps), and 4 Ethernet LAN ports (1 Gbps) to meet demanding data transfer needs via cable.
• Dual-band Wi-Fi broadcasting: Supports simultaneous wireless transmission on both 2.4GHz and 5GHz bands, using 2x2 MIMO technology for each band to ensure strong and stable wireless performance.
• Broad device compatibility: Works seamlessly with a wide range of wireless devices such as smartphones, laptops, smart TVs, and other connected home devices.
• Flexible Mesh Wi-Fi support: Easily integrates with VNPT Technology’s Mesh Wi-Fi Access Points, enabling extended wireless coverage and seamless roaming throughout the network.
• Compatible with multiple OLT brands: Ensures flexible deployment with popular OLT equipment from vendors such as Nokia, Huawei, ZTE, and Dasan.
• Versatile deployment options: Ideal for various network models including FTTH (Fiber to the Home), FTTB (Fiber to the Building), and POL (Passive Optical LAN) in households, businesses, and educational institutions.
• Compliant with international standards: Fully adheres to the ITU-T G.9807.1 standard, ensuring high levels of network stability, reliability, and data transmission security.

Specifications:

Download Documents:
